Standard |
Options |
| Mainframe |
12" Channel @ 25#/ft
|
|
| Crossmembers |
4" Channel @ 5.4#/ft
|
|
| Siderails |
6" Channel @ 8.2#/ft
|
|
| Rubrail |
Heavy-Duty 4" Rubrail with 5" Stake Pockets
|
|
| Stoprails |
12" Channel @ 25#/ft
|
|
| Axles |
3x 20,000# Dual Wheel Commercial Grade Air Brakes
|
|
| Flooring |
Oak Decking
|
Steel Decking
|
| Tires |
215/75/R17.5 16-Ply
|
|
| Brakes |
Air Brakes
|
|
| Suspension |
Heavy-Duty Hutch Kit
|
|
| Wheels |
17.5" 8-Lug
|
|
| Bed Height |
40" from ground level (approx)
|
|
| Hitch Type |
Multi-Position Pintle Hitch
|
|
| Jack |
Dual Jacks
|
Dual 2-Speed Jacks Hydraulic Jack Dual Hydraulic Jacks
|
| Safety Chains |
1/2" Grade-70 Safety Chains with Hooks
|
|
| Stake Pockets |
5" Stake Pockets spaced behind Rubrails
|
Stake Pocket D-Rings
|
| Trailer Plug |
7-Pin RV-Style
|
|
| Lighting |
LED Lighting (Grommet Mounted)
|
|
| Wiring |
Sealed Modular All-Weather Harness
|
|
| Paint Type |
Professional Finish
|
|
| Mudflaps |
Standard 'Econoline Trailers' Mudflaps
|
|
| Storage |
Chain Storage
|
Chain Storage with Locking Lid
|
| Pipe Chain Spools |
3" Pipe Chain Spools between Stake Pockets
|
|
| |
|
